NBR Food Discharge Hose

Inquiry Form

The flexible NBR food discharge hose features a smooth white FDA-approved nitrile rubber tube, ensuring compliance with stringent food safety standards. This design makes it ideal for a wide range of food liquid processing applications, providing flexibility and reliability in food handling processes.

Basic Information
  • Inner tube: Nitrile Rubber (tensile strength ≥10MPa)
  • Reinforcement layer: Fabric Cord Wrapping
  • Outer cover: Nitrile Rubber (tensile strength ≥11MPa)
  • Operating temperature: -40°C to 90°C
  • Safety factor: 3:1
  • Color: Available in various colors such as blue and green.

Features
Made from oil-resistant nitrile rubber, this hose boasts exceptional durability against oils. It undergoes rigorous testing, including checks for ester and heavy metal content, as well as water and n-hexane extraction, ensuring compliance with SGS standards. With its primary application in the food processing industry, it is ideal for transporting edible oils, milk, and other food products with confidence and reliability.

Applications
Primarily utilized in the food processing industry, this hose is designed for the transportation of edible oils, milk, and various other food products.

Technical Parameters

Item Code Inner Diameter Outer Diameter Working Pressure Burst Pressure Weight Max. Length
mm inch mm bar psi bar psi kg/m m
NBR-FDD019-150 19 3/4" 30.4 10 150 30 450 0.63 40
NBR-FDD025-150 25 1" 36.4 10 150 30 450 0.78 40
NBR-FDD032-150 32 1-1/4" 43.8 10 150 30 450 1.02 40
NBR-FDD038-150 38 1-1/2" 50.8 10 150 30 450 1.29 40
NBR-FDD045-150 45 1-3/4" 57.8 10 150 30 450 1.49 40
NBR-FDD051-150 51 2" 63.8 10 150 30 450 1.66 40
NBR-FDD064-150 64 2-1/2" 77.8 10 150 30 450 2.22 40
NBR-FDD076-150 76 3" 89.8 10 150 30 450 2.60 40
NBR-FDD102-150 102 4" 116.6 10 150 30 450 3.73 40
NBR-FDD019-230 19 3/4" 30.4 16 230 48 690 0.63 40
NBR-FDD019-230 25 1" 36.4 16 230 48 690 0.78 40
NBR-FDD019-230 32 1-1/4" 43.8 16 230 48 690 1.02 40
NBR-FDD019-230 38 1-1/2" 51.2 16 230 48 690 1.30 40
NBR-FDD019-230 45 1-3/4" 58.2 16 230 48 690 1.51 40
NBR-FDD019-230 51 2" 64.2 16 230 48 690 1.68 40
NBR-FDD019-230 64 2-1/2" 78.6 16 230 48 690 2.43 40
NBR-FDD019-230 76 3" 90.6 16 230 48 690 2.84 40
NBR-FDD019-230 102 4" 119.4 16 230 48 690 4.58 40

Note: specifications, pressures, colors and other parameters can be customized according to customers' requirements.
