Heavy Duty Rubber Oil Suction and Delivery Hose Tank Truck Hose
Designed with copper wire, the heavy duty oil suction and delivery hose is characterized by antistatic electricity and good resistance to vacuum. Suitable for connecting with tank trucks, this heavy duty oil hose is widely used for delivering various petroleum products with aromatic content higher than 50%.
Construction
Tube: NBR
Reinforcement: High tensile textile cord with helix steel wire
Cover rubber: NBR+CR
Safety factor: 3:1
Temperature Range
-40℃~80℃
Standard Compliance
HT/T2540-93
Technical Parameters
| I.D | O.D | W.P | B.P. | Weight | Length | ||||
| mm | inch | mm | psi | bar | psi | bar | kg/m | ft | m |
| 51 | 2" | 65 | 150 | 10 | 450 | 30 | 2.01 | 200 | 61 |
| 64 | 2-1/2" | 80 | 150 | 10 | 450 | 30 | 3.02 | 200 | 61 |
| 76 | 3" | 92 | 150 | 10 | 450 | 30 | 3.51 | 200 | 61 |
| 102 | 4" | 120 | 150 | 10 | 450 | 30 | 5.17 | 200 | 61 |
| 127 | 5" | 147 | 150 | 10 | 450 | 30 | 7.63 | 200 | 61 |
| 152 | 6" | 172 | 150 | 10 | 450 | 30 | 9.01 | 200 | 61 |
Note: Specifications can be made upon request.
